Power: 7000 (kW) |

SKU: RLGBMM705DB |

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
1000-7000 / 860-6023
(kW) / (Mcal/h)
NOx Class
II
Turn Down Ratio
1:7
G20 Gas Rated Output
1000-7000
kW
G20 Gas Flow Rate
100-700
m3/h
G25 Gas Rated Output
1000-7000
kW
G25 Gas Flow Rate
116-814
m3/h
LPG Rated Output
1500-7000
kW
LPG Gas Flow Rate
58-271
m3/h
Light Oil Rated Output
1400-7000
kW
Light Oil Flow Rate
287-1433
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
243-360
mbar
Gas Line Pressure (High Pressure type)
2-4
bar
Input Gas Pipe Size (Low Pressure)
DN80
Input Gas Pipe Size (High Pressure)
DN80
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
kW
Fan Motor Speed
rpm
Pump Model
TA5
Pump Motor Power
1.5
kW
Pump Motor Speed
2840
rpm
Gas Operation Mode
Electrical Modular
Oil Operation Mode
Electrical Modular
Centrifugal Fan
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
1693x995x850
mm
Weight
420
Kg

RLGB-M/M-705-DB

Power: 7000 (kW)

SKU: RLGBMM705DB

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
1000-7000 / 860-6023
(kW) / (Mcal/h)
NOx Class
II
Turn Down Ratio
1:7
G20 Gas Rated Output
1000-7000
kW
G20 Gas Flow Rate
100-700
m3/h
G25 Gas Rated Output
1000-7000
kW
G25 Gas Flow Rate
116-814
m3/h
LPG Rated Output
1500-7000
kW
LPG Gas Flow Rate
58-271
m3/h
Light Oil Rated Output
1400-7000
kW
Light Oil Flow Rate
287-1433
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
243-360
mbar
Gas Line Pressure (High Pressure type)
2-4
bar
Input Gas Pipe Size (Low Pressure)
DN80
Input Gas Pipe Size (High Pressure)
DN80
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
kW
Fan Motor Speed
rpm
Pump Model
TA5
Pump Motor Power
1.5
kW
Pump Motor Speed
2840
rpm
Gas Operation Mode
Electrical Modular
Oil Operation Mode
Electrical Modular
Centrifugal Fan
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
1693x995x850
mm
Weight
420
Kg
Burner Type L1 L2 L3 L4 L5 L6 L7 H1 H2 D1 D2 D3 N1 N2 B.C.D1 B.C.D2
RLGB-M/M-705-DB
1688
425
949
534
450
418
487
850
598
400
20
20
4
4
540
700
Gas Operation
Nox (mg/kW.h)
CO (ppm)
120
20
Light Oil Operation
Nox (mg/kW.h)
CO (ppm)
170
30

Gas Operation

Nox (mg/kW.h) CO (ppm)
120
20

Light Oil Operation

Nox (mg/kW.h) CO (ppm)
170
30
