SKU: RGBM505LN-TR
| Technical Data | Value | Unit |
|---|---|---|
| Heat Rated Output | 700-5100 / 602-4388 | (kW) / (Mcal/h) |
| NOx Class | III | — |
| Turn Down Ratio | 1:7 | — |
| G20 Gas Rated Output | 700-5100 | kW |
| G20 Gas Flow Rate | 70-510 | m3/h |
| G25 Gas Rated Output | 700-5100 | kW |
| G25 Gas Flow Rate | 81-593 | m3/h |
| LPG Rated Output | 750-5100 | kW |
| LPG Gas Flow Rate | 29-198 | m3/h |
| Light Oil Rated Output | -- | kW |
| Light Oil Flow Rate | -- | kg/h |
| Heavy Oil Rated Output | -- | kW |
| Heavy Oil Flow Rate | -- | kg/h |
| Gas Line Pressure (Low Pressure) | 146-360 | mbar |
| Gas Line Pressure (High Pressure Type) | 1.5-4 | bar |
| Input Gas Pipe Size (Low Pressure) | DN 80 | — |
| Input Gas Pipe Size (High Pressure) | DN 80 | — |
| Electric Power Supply Phase | 3 | ph |
| Electric Power Supply Frequency | 50 | Hz |
| Electric Power Supply Voltage | 380-400 | V |
| Fan Electrical Motor Power | 11 | kW |
| Fan Motor Speed | 2900 | rpm |
| Pump Model | -- | — |
| Pump Motor Power | -- | kW |
| Pump Motor Speed | -- | rpm |
| Gas Operation Mode | Electrical Modular | — |
| Oil Operation Mode | -- | — |
| Centrifugal Fan | 363x103x42 | mm |
| IP (With reference to ISIRI 2868) | 43 | — |
| Total Dimension | 1720x925x800 | mm |
| Weight | 221 | Kg |
| Burner Type | L1 | L2 | L3 | W1 | H1 | H2 | D1 | D2 | D3 | D4 | N | N1 | N2 | B.C.D | B.C.D1 | B.C.D2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| RGB-M-505/LN | 1721 | 552 | 433 | 930.0 | 798 | 413 | 328.0 | 20 | -- | -- | 4 | -- | -- | 490 | -- | -- |
| Gas Operation | |
|---|---|
| Nox (mg/kW.h) | CO (ppm) |
| 80 | 20 |
| Burner Card | |
|---|---|
| Download | |
| Proposal | STP |
|---|---|
Download | Download |
