Power: 10500 (kW) |

SKU: RLGBMM1050DB |

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
1000-10500 / 860-9034
(kW) / (Mcal/h)
NOx Class
II
Turn Down Ratio
1:10
G20 Gas Rated Output
1000-10500
kW
G20 Gas Flow Rate
100-1050
m3/h
G25 Gas Rated Output
1000-10500
kW
G25 Gas Flow Rate
116-1221
m3/h
LPG Rated Output
1500-10500
kW
LPG Gas Flow Rate
58-407
m3/h
Light Oil Rated Output
2100-10500
kW
Light Oil Flow Rate
177-885
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
139-360
mbar
Gas Line Pressure (High Pressure type)
4
bar
Input Gas Pipe Size (Low Pressure)
DN 100
Input Gas Pipe Size (High Pressure)
DN 100
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
22
kW
Fan Motor Speed
2850
rpm
Pump Model
T3
Pump Motor Power
2.2
kW
Pump Motor Speed
2840
rpm
Gas Operation Mode
Electrical Modular
Oil Operation Mode
Electrical Modular
Centrifugal Fan
595x160x48
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
1845x1095x865
mm
Weight
460
Kg

RLGB-M/M-1050-DB

Power: 10500 (kW)

SKU: RLGBMM1050DB

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
1000-10500 / 860-9034
(kW) / (Mcal/h)
NOx Class
II
Turn Down Ratio
1:10
G20 Gas Rated Output
1000-10500
kW
G20 Gas Flow Rate
100-1050
m3/h
G25 Gas Rated Output
1000-10500
kW
G25 Gas Flow Rate
116-1221
m3/h
LPG Rated Output
1500-10500
kW
LPG Gas Flow Rate
58-407
m3/h
Light Oil Rated Output
2100-10500
kW
Light Oil Flow Rate
177-885
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
139-360
mbar
Gas Line Pressure (High Pressure type)
4
bar
Input Gas Pipe Size (Low Pressure)
DN 100
Input Gas Pipe Size (High Pressure)
DN 100
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
22
kW
Fan Motor Speed
2850
rpm
Pump Model
T3
Pump Motor Power
2.2
kW
Pump Motor Speed
2840
rpm
Gas Operation Mode
Electrical Modular
Oil Operation Mode
Electrical Modular
Centrifugal Fan
595x160x48
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
1845x1095x865
mm
Weight
460
Kg
Burner Type L1 L2 W1 L4 L5 L6 L7 H1 H2 D1 D2 D3 N1 N2 B.C.D1 B.C.D2
RLGB-M/M-1050-DB
1857
428
1095
584
500
418
487
865
660
480
20
20
4
4
590
790
Gas Operation
Nox (mg/kW.h)
CO (ppm)
80
20
Light Oil Operation
Nox (mg/kW.h)
CO (ppm)
170
30

Gas Operation

Nox (mg/kW.h) CO (ppm)
80
20

Light Oil Operation

Nox (mg/kW.h) CO (ppm)
170
30
