RPB-M-15/PE

Low Nox Burner
Power: 150 (kW)

SKU: RPBM15PE

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
38-150 / 33-129
(kW) / (Mcal/h)
NOx Class
Ultra Low Nox
Turn Down Ratio
1:4
G20 Gas Rated Output
38-150
kW
G20 Gas Flow Rate
4-15
m3/h
G25 Gas Rated Output
38-150
kW
G25 Gas Flow Rate
4-17
m3/h
LPG Rated Output
kW
LPG Gas Flow Rate
m3/h
Light Oil Rated Output
kW
Light Oil Flow Rate
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
mbar
Gas Line Pressure (High Pressure type)
bar
Input Gas Pipe Size (Low Pressure)
Rp 1
Input Gas Pipe Size (High Pressure)
Electric Power Supply Phase
1
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
0.2
kW
Fan Motor Speed
8000
rpm
Pump Model
Pump Motor Power
kW
Pump Motor Speed
rpm
Gas Operation Mode
Oil Operation Mode
Centrifugal Fan
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
745x285x310
mm
Weight
18
Kg

Burner Type L1 L2 L3 L4 L5 D1 D2 D3 D4 N B.C.D
RPB-M-15/PE
745
442
204
238
--
98
6..6
185
228
8
265
RPB-M-15-PE-Dimension pe series primixed burner

Gas Operation
Nox (mg/kW.h)
CO (ppm)
40
2

Gas Operation

Nox (mg/kW.h) CO (ppm)
40
2
