RGB-M-145

Power: 1480 (kW)

SKU: RGBM145

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
400-1480 / 344-1273
(kW) / (Mcal/h)
NOx Class
II
Turn Down Ratio
1:4
G20 Gas Rated Output
400-1480
kW
G20 Gas Flow Rate
40-148
m3/h
G25 Gas Rated Output
400-1480
kW
G25 Gas Flow Rate
47-172
m3/h
LPG Rated Output
500-1450
kW
LPG Gas Flow Rate
19-57
m3/h
Light Oil Rated Output
kW
Light Oil Flow Rate
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
52-138
mbar
Gas Line Pressure (High Pressure type)
bar
Input Gas Pipe Size (Low Pressure)
Rp 2
Input Gas Pipe Size (High Pressure)
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
2.2
kW
Fan Motor Speed
2840
rpm
Pump Model
Pump Motor Power
kW
Pump Motor Speed
rpm
Gas Operation Mode
Electrical Modular
Oil Operation Mode
Centrifugal Fan
387x61x24
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
1097x638x600
mm
Weight
78
Kg

Burner Type L1 L2 L3 H1 H2 D1 D2 D3 D4 N N1 N2 B.C.D B.C.D1 B.C.D2
RGB-M-145
1097
285
638
598
265
194
15
--
--
4
--
--
--
270
320
RGB-M-145-Dimension Monoblock electrical modular gas burner

RGB-M-145-Diagram Monoblock electrical modular gas burner

Gas Operation
Nox (mg/kW.h)
CO (ppm)
120
30

Gas Operation

Nox (mg/kW.h) CO (ppm)
120
30
