RPB-M-300/PM

Low Nox Burner
Power: 3000 (kW)

SKU: RPBM300PM

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
750-3000 / 645-2581
(kW) / (Mcal/h)
NOx Class
Ultra Low Nox
Turn Down Ratio
1:4
G20 Gas Rated Output
750-3000
kW
G20 Gas Flow Rate
75-300
m3/h
G25 Gas Rated Output
750-3000
kW
G25 Gas Flow Rate
87-349
m3/h
LPG Rated Output
kW
LPG Gas Flow Rate
m3/h
Light Oil Rated Output
kW
Light Oil Flow Rate
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
0
mbar
Gas Line Pressure (High Pressure type)
bar
Input Gas Pipe Size (Low Pressure)
DN65
Input Gas Pipe Size (High Pressure)
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
7
kW
Fan Motor Speed
2850
rpm
Pump Model
Pump Motor Power
kW
Pump Motor Speed
rpm
Gas Operation Mode
Oil Operation Mode
Centrifugal Fan
315x104x38
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
2813x1176x805
mm
Weight
85
Kg

Burner Type L1 L2 L3 L4 L5 D1 D2 D3 D4 N B.C.D
RPB-M-300/PM
2813
1591
1374
211
1176
300
11
580
477
8
550

Gas Operation
Nox (mg/kW.h)
CO (ppm)
40
20

Gas Operation

Nox (mg/kW.h) CO (ppm)
40
20
