Power: 8000 (kW) |

SKU: RGBM805SF |

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
1000-8000 / 860-6883
(kW) / (Mcal/h)
NOx Class
II
Turn Down Ratio
1:8
G20 Gas Rated Output
1000-8000
kW
G20 Gas Flow Rate
100-800
m3/h
G25 Gas Rated Output
1000-8000
kW
G25 Gas Flow Rate
116-930
m3/h
LPG Rated Output
1600-8000
kW
LPG Gas Flow Rate
62-310
m3/h
Light Oil Rated Output
kW
Light Oil Flow Rate
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
185-360
mbar
Gas Line Pressure (High Pressure type)
2.5-4
bar
Input Gas Pipe Size (Low Pressure)
DN 100
Input Gas Pipe Size (High Pressure)
DN 80
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
18.5
kW
Fan Motor Speed
2840
rpm
Pump Model
Pump Motor Power
kW
Pump Motor Speed
rpm
Gas Operation Mode
Electrical Modular
Oil Operation Mode
Centrifugal Fan
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
2091 x1165x950
mm
Weight
~591
Kg

RGB-M-805-SF

Power: 8000 (kW)

SKU: RGBM805SF

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
1000-8000 / 860-6883
(kW) / (Mcal/h)
NOx Class
II
Turn Down Ratio
1:8
G20 Gas Rated Output
1000-8000
kW
G20 Gas Flow Rate
100-800
m3/h
G25 Gas Rated Output
1000-8000
kW
G25 Gas Flow Rate
116-930
m3/h
LPG Rated Output
1600-8000
kW
LPG Gas Flow Rate
62-310
m3/h
Light Oil Rated Output
kW
Light Oil Flow Rate
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
185-360
mbar
Gas Line Pressure (High Pressure type)
2.5-4
bar
Input Gas Pipe Size (Low Pressure)
DN 100
Input Gas Pipe Size (High Pressure)
DN 80
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
18.5
kW
Fan Motor Speed
2840
rpm
Pump Model
Pump Motor Power
kW
Pump Motor Speed
rpm
Gas Operation Mode
Electrical Modular
Oil Operation Mode
Centrifugal Fan
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
2091 x1165x950
mm
Weight
~591
Kg
Burner Type L1 L2 L3 H1 H2 D1 D2 D3 D4 N N1 N2 B.C.D B.C.D1 B.C.D2
RGB-M-805-SF
2091
350
1165
950
501
400
22
4
590
Gas Operation
Nox (mg/kW.h)
CO (ppm)
120
30

Gas Operation

Nox (mg/kW.h) CO (ppm)
120
30
