the best industrial burner, boiler burner and furnace burner in the world

RGB-M-1250/DB

Power: 12000 (kW)

SKU: RGB1250DB

0.0/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
1200-12000 / 1033-10325
(kW) / (Mcal/h)
NOx Class
II
Turn Down Ratio
1:10
G20 Gas Rated Output
1200-12000
kW
G20 Gas Flow Rate
120-1200
m3/h
G25 Gas Rated Output
1200-12000
kW
G25 Gas Flow Rate
140-1395
m3/h
LPG Rated Output
2000-12000
kW
LPG Gas Flow Rate
78-407
m3/h
Light Oil Rated Output
kW
Light Oil Flow Rate
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
242-360
mbar
Gas Line Pressure (High Pressure type)
4
bar
Input Gas Pipe Size (Low Pressure)
DN 100
Input Gas Pipe Size (High Pressure)
DN 100
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
kW
Fan Motor Speed
rpm
Pump Model
Pump Motor Power
kW
Pump Motor Speed
rpm
Gas Operation Mode
Electrical Modular
Lamtec
Oil Operation Mode
Lamtec
Centrifugal Fan
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
1838x1095x865
mm
Weight
460
Kg
{{ reviewsTotal }}{{ options.labels.singularReviewCountLabel }}
{{ reviewsTotal }}{{ options.labels.pluralReviewCountLabel }}
{{ options.labels.newReviewButton }}
{{ userData.canReview.message }}

Burner Type L1 L2 L3 L4 L5 L6 L7 H1 H2 D1 D2 D3 N1 N2 B.C.D1 B.C.D2
RGB-M-1250/DB
1838
367
1095
584
500
418
487
865
660
590
20
20
4
4
590
790
RGB-M-1250-DB-Dimension ELECTRICAL DUAL BLOCK GAS BURNER

RGB-M-1250-DB-Diagram ELECTRICAL DUAL BLOCK GAS BURNER

Gas Operation
Nox (mg/kW.h)
CO (ppm)
120
30

Gas Operation

Nox (mg/kW.h) CO (ppm)
120
30
