SKU: RGBM705
| Technical Data | Value | Unit |
|---|---|---|
| Heat Rated Output | 1000-7000 / 860-6023 | (kW) / (Mcal/h) |
| NOx Class | II | — |
| Turn Down Ratio | 1:7 | — |
| G20 Gas Rated Output | 1000-7000 | kW |
| G20 Gas Flow Rate | 100-700 | m3/h |
| G25 Gas Rated Output | 1000-7000 | kW |
| G25 Gas Flow Rate | 116-814 | m3/h |
| LPG Rated Output | 1500-7000 | kW |
| LPG Gas Flow Rate | 58-271 | m3/h |
| Light Oil Rated Output | -- | kW |
| Light Oil Flow Rate | -- | kg/h |
| Heavy Oil Rated Output | -- | kW |
| Heavy Oil Flow Rate | -- | kg/h |
| Gas Line Pressure (Low Pressure) | 243-360 | mbar |
| Gas Line Pressure (High Pressure Type) | 2-4 | bar |
| Input Gas Pipe Size (Low Pressure) | DN80 | — |
| Input Gas Pipe Size (High Pressure) | DN80 | — |
| Electric Power Supply Phase | 3 | ph |
| Electric Power Supply Frequency | 50 | Hz |
| Electric Power Supply Voltage | 380-400 | V |
| Fan Electrical Motor Power | 18.5 | kW |
| Fan Motor Speed | 2840 | rpm |
| Pump Model | -- | — |
| Pump Motor Power | -- | kW |
| Pump Motor Speed | -- | rpm |
| Gas Operation Mode | Electrical Modular | — |
| Oil Operation Mode | -- | — |
| Centrifugal Fan | -- | mm |
| IP (With reference to ISIRI 2868) | 43 | — |
| Total Dimension | 2191x950x1165 | mm |
| Weight | 590 | Kg |
| Technical Data | Value | Unit |
|---|---|---|
| Heat Rated Output | 1000-7000 / 860-6023 | (kW) / (Mcal/h) |
| NOx Class | II | — |
| Turn Down Ratio | 1:7 | — |
| G20 Gas Rated Output | 1000-7000 | kW |
| G20 Gas Flow Rate | 100-700 | m3/h |
| G25 Gas Rated Output | 1000-7000 | kW |
| G25 Gas Flow Rate | 116-814 | m3/h |
| LPG Rated Output | 1500-7000 | kW |
| LPG Gas Flow Rate | 58-271 | m3/h |
| Light Oil Rated Output | -- | kW |
| Light Oil Flow Rate | -- | kg/h |
| Heavy Oil Rated Output | -- | kW |
| Heavy Oil Flow Rate | -- | kg/h |
| Gas Line Pressure (Low pressure) | 243-360 | mbar |
| Gas Line Pressure (High Pressure type) | 2-4 | bar |
| Input Gas Pipe Size (Low Pressure) | DN80 | — |
| Input Gas Pipe Size (High Pressure) | DN80 | — |
| Electric Power Supply Phase | 3 | ph |
| Electric Power Supply Frequency | 50 | Hz |
| Electric Power Supply Voltage | 380-400 | V |
| Fan Electrical Motor Power | 18.5 | kW |
| Fan Motor Speed | 2840 | rpm |
| Pump Model | -- | — |
| Pump Motor Power | -- | kW |
| Pump Motor Speed | -- | rpm |
| Gas Operation Mode | Electrical Modular | — |
| Oil Operation Mode | -- | — |
| Centrifugal Fan | -- | mm |
| IP (With reference to ISIRI 2868) | 43 | — |
| Total Dimension | 2191x950x1165 | mm |
| Weight | 590 | Kg |
| Burner Type | L1 | L2 | L3 | W1 | H1 | H2 | D1 | D2 | D3 | D4 | N | N1 | N2 | B.C.D | B.C.D1 | B.C.D2 | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| RGB-M-705 | 2161 | 420 | -- | 1165 | 948 | 501 | 400 | 22 | -- | -- | 4 | -- | -- | 590 | -- | -- | ||||
| Burner Type | L1 | L2 | W1 | L3 | L4 | L5 | L6 | L7 | H1 | H2 | D1 | D2 | D3 | D4 | N | N1 | N2 | B.C.D | B.C.D1 | B.C.D2 | RGB-M-705 | 2161 | 420 | 1165 | -- | -- | -- | -- | -- | 948 | 501 | 400 | 22 | -- | -- | 4 | -- | -- | 590 | -- | -- |
|---|
| Gas Operation | |
|---|---|
| Nox (mg/kW.h) | CO (ppm) |
| 80 | 20 |
| Burner Card | |
|---|---|
| Download | |
| Proposal | STP |
|---|---|
| Download If you need STP and Proposal files, you need a VIP account. | Download If you need STP and Proposal files, you need a VIP account. |
