SKU: RGBMC185
| Technical Data | Value | Unit |
|---|---|---|
| Heat Rated Output | 470-1870 / 405-1609 | (kW) / (Mcal/h) |
| NOx Class | II | — |
| Turn Down Ratio | 1:4 | — |
| G20 Gas Rated Output | 470-1870 | kW |
| G20 Gas Flow Rate | 47-187 | m3/h |
| G25 Gas Rated Output | 470-1870 | kW |
| G25 Gas Flow Rate | 55-217 | m3/h |
| LPG Rated Output | 500-1870 | kW |
| LPG Gas Flow Rate | 19-72 | m3/h |
| Light Oil Rated Output | -- | kW |
| Light Oil Flow Rate | -- | kg/h |
| Heavy Oil Rated Output | -- | kW |
| Heavy Oil Flow Rate | -- | kg/h |
| Gas Line Pressure (Low Pressure) | 105-360 | mbar |
| Gas Line Pressure (High Pressure Type) | -- | bar |
| Input Gas Pipe Size (Low Pressure) | Rp 2 | — |
| Input Gas Pipe Size (High Pressure) | -- | — |
| Electric Power Supply Phase | 3 | ph |
| Electric Power Supply Frequency | 50 | Hz |
| Electric Power Supply Voltage | 380-400 | V |
| Fan Electrical Motor Power | 5.5 | kW |
| Fan Motor Speed | 2840 | rpm |
| Pump Model | -- | — |
| Pump Motor Power | -- | kW |
| Pump Motor Speed | -- | rpm |
| Gas Operation Mode | Mechanical Modular | — |
| Oil Operation Mode | -- | — |
| Centrifugal Fan | 345x66x28 | mm |
| IP (With reference to ISIRI 2868) | 43 | — |
| Total Dimension | 1230x665x600 | mm |
| Weight | 100 | Kg |
| Technical Data | Value | Unit |
|---|---|---|
| Heat Rated Output | 470-1870 / 405-1609 | (kW) / (Mcal/h) |
| NOx Class | II | — |
| Turn Down Ratio | 1:4 | — |
| G20 Gas Rated Output | 470-1870 | kW |
| G20 Gas Flow Rate | 47-187 | m3/h |
| G25 Gas Rated Output | 470-1870 | kW |
| G25 Gas Flow Rate | 55-217 | m3/h |
| LPG Rated Output | 500-1870 | kW |
| LPG Gas Flow Rate | 19-72 | m3/h |
| Light Oil Rated Output | -- | kW |
| Light Oil Flow Rate | -- | kg/h |
| Heavy Oil Rated Output | -- | kW |
| Heavy Oil Flow Rate | -- | kg/h |
| Gas Line Pressure (Low pressure) | 105-360 | mbar |
| Gas Line Pressure (High Pressure type) | -- | bar |
| Input Gas Pipe Size (Low Pressure) | Rp 2 | — |
| Input Gas Pipe Size (High Pressure) | -- | — |
| Electric Power Supply Phase | 3 | ph |
| Electric Power Supply Frequency | 50 | Hz |
| Electric Power Supply Voltage | 380-400 | V |
| Fan Electrical Motor Power | 5.5 | kW |
| Fan Motor Speed | 2840 | rpm |
| Pump Model | -- | — |
| Pump Motor Power | -- | kW |
| Pump Motor Speed | -- | rpm |
| Gas Operation Mode | Mechanical Modular | — |
| Oil Operation Mode | -- | — |
| Centrifugal Fan | 345x66x28 | mm |
| IP (With reference to ISIRI 2868) | 43 | — |
| Total Dimension | 1230x665x600 | mm |
| Weight | 100 | Kg |
| Burner Type | L1 | L2 | L3 | W1 | H1 | H2 | D1 | D2 | D3 | D4 | N | N1 | N2 | B.C.D | B.C.D1 | B.C.D2 | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| RGB-MC-185 | 1229 | 387 | -- | 665 | 598 | 301 | 223 | 18 | -- | -- | 4 | -- | -- | -- | 323 | 367 | ||||
| Burner Type | L1 | L2 | W1 | L3 | L4 | L5 | L6 | L7 | H1 | H2 | D1 | D2 | D3 | D4 | N | N1 | N2 | B.C.D | B.C.D1 | B.C.D2 | RGB-MC-185 | 1229 | 387 | 665 | -- | 598 | 301 | 223 | 18 | -- | -- | 4 | -- | -- | -- | 323 | 367 |
|---|
