RLGB-175/LN

Low Nox Burner
Power: 1800 (kW)

SKU: RLGB175LN

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
320-1800 / 275-1549
(kW) / (Mcal/h)
NOx Class
III
Turn Down Ratio
1:5
G20 Gas Rated Output
320-1800
kW
G20 Gas Flow Rate
32-180
m3/h
G25 Gas Rated Output
320-1800
kW
G25 Gas Flow Rate
37-209
m3/h
LPG Rated Output
320-1800
kW
LPG Gas Flow Rate
12-70
m3/h
Light Oil Rated Output
320-1800
kW
Light Oil Flow Rate
27-152
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
75-138
mbar
Gas Line Pressure (High Pressure type)
bar
Input Gas Pipe Size (Low Pressure)
Rp 2
Input Gas Pipe Size (High Pressure)
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
4
kW
Fan Motor Speed
2840
rpm
Pump Model
J7
Pump Motor Power
0.55
kW
Pump Motor Speed
2840
rpm
Gas Operation Mode
Double Stage
Oil Operation Mode
Double Stage
Centrifugal Fan
360x66x28
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
1213x875x600
mm
Weight
116
Kg

Burner Type L1 L2 L3 H1 H2 D1 D2 D3 D4 N N1 N2 B.C.D B.C.D1 B.C.D2
RLGB-175/LN
1068
255
797
600
265
180
15
--
--
4
--
--
295
--
--
RLGB-175-LN-Dimension dual fuel staging mono block burner

RLGB-175-Diagram-1 dual fuel staging mono block burner

Gas Operation
Nox (mg/kW.h)
CO (ppm)
80
20
Light Oil Operation
Nox (mg/kW.h)
CO (ppm)
170
30

Gas Operation

Nox (mg/kW.h) CO (ppm)
80
20

Light Oil Operation

Nox (mg/kW.h) CO (ppm)
170
30
