Power: 215 (kW) |

SKU: RGB20 |

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
85-215 / 73-185
(kW) / (Mcal/h)
NOx Class
No
Turn Down Ratio
1:2
G20 Gas Rated Output
85-215
kW
G20 Gas Flow Rate
10-22
m3/h
G25 Gas Rated Output
85-215
kW
G25 Gas Flow Rate
10-22
m3/h
LPG Rated Output
85-215
kW
LPG Gas Flow Rate
3-8
m3/h
Light Oil Rated Output
kW
Light Oil Flow Rate
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
9-18
mbar
Gas Line Pressure (High Pressure type)
bar
Input Gas Pipe Size (Low Pressure)
Rp 1
Input Gas Pipe Size (High Pressure)
Electric Power Supply Phase
1
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
220
V
Fan Electrical Motor Power
0.3
kW
Fan Motor Speed
2700
rpm
Pump Model
Pump Motor Power
kW
Pump Motor Speed
rpm
Gas Operation Mode
One stage
Oil Operation Mode
Centrifugal Fan
160x62x12.7
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
561x313x304
mm
Weight
18
Kg

RGB-20

Power: 215 (kW)

SKU: RGB20

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
85-215 / 73-185
(kW) / (Mcal/h)
NOx Class
No
Turn Down Ratio
1:2
G20 Gas Rated Output
85-215
kW
G20 Gas Flow Rate
10-22
m3/h
G25 Gas Rated Output
85-215
kW
G25 Gas Flow Rate
10-22
m3/h
LPG Rated Output
85-215
kW
LPG Gas Flow Rate
3-8
m3/h
Light Oil Rated Output
kW
Light Oil Flow Rate
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
9-18
mbar
Gas Line Pressure (High Pressure type)
bar
Input Gas Pipe Size (Low Pressure)
Rp 1
Input Gas Pipe Size (High Pressure)
Electric Power Supply Phase
1
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
220
V
Fan Electrical Motor Power
0.3
kW
Fan Motor Speed
2700
rpm
Pump Model
Pump Motor Power
kW
Pump Motor Speed
rpm
Gas Operation Mode
One stage
Oil Operation Mode
Centrifugal Fan
160x62x12.7
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
561x313x304
mm
Weight
18
Kg
Burner Type L1 L2 L3 W1 H1 H2 D1 D2 D3 D4 N N1 N2 B.C.D B.C.D1 B.C.D2
RGB-20
561
142
313
304
125
9
170
4
150
RGB-20-Diagram GAS STAGING MONO BLOCK BURNER
Gas Operation
Nox (mg/kW.h)
CO (ppm)
120
30

Gas Operation

Nox (mg/kW.h) CO (ppm)
120
30
