| Heat Rated Output | 1000-7000 / 860-6023 | (kW) / (Mcal/h) |
| NOx Class | II | — |
| Turn Down Ratio | 1:7 | — |
| G20 Gas Rated Output | 1000-7000 | kW |
| G20 Gas Flow Rate | 100-700 | m³/h |
| G25 Gas Rated Output | 1000-7000 | kW |
| G25 Gas Flow Rate | 116-814 | m³/h |
| LPG Rated Output | 1400-7000 | kW |
| LPG Gas Flow Rate | 54-271 | m³/h |
| Light Oil Rated Output | -- | kW |
| Light Oil Flow Rate | -- | kg/h |
| Heavy Oil Rated Output | -- | kW |
| Heavy Oil Flow Rate | -- | kg/h |
| Gas Line Pressure (Low Pressure) | 236-360 | mbar |
| Gas Line Pressure (High Pressure Type) | 2-4 | bar |
| Input Gas Pipe Size (Low Pressure) | DN80 | — |
| Input Gas Pipe Size (High Pressure) | DN80 | — |
| Electric Power Supply Phase | 3 | ph |
| Electric Power Supply Frequency | 50 | Hz |
| Electric Power Supply Voltage | 380-400 | V |
| Fan Electrical Motor Power | 18.5 | kW |
| Fan Motor Speed | 2840 | rpm |
| Pump Model | -- | — |
| Pump Motor Power | -- | kW |
| Pump Motor Speed | -- | rpm |
| Gas Operation Mode | Electrical Modular | — |
| Oil Operation Mode | -- | — |
| Centrifugal Fan | 550x 127x 142 | mm |
| IP (With reference to ISIRI 2868) | 43 | — |
| Total Dimension | 2091x1370x960 | mm |
| Weight | ~416 | Kg |
