Power: 5100 (kW) |

SKU: RLGBMM505LN |

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
700-5100 / 602-4388
(kW) / (Mcal/h)
NOx Class
III
Turn Down Ratio
1:7
G20 Gas Rated Output
700-5100
kW
G20 Gas Flow Rate
70-510
m3/h
G25 Gas Rated Output
700-5100
kW
G25 Gas Flow Rate
81-593
m3/h
LPG Rated Output
750-5100
kW
LPG Gas Flow Rate
29-198
m3/h
Light Oil Rated Output
700-5100
kW
Light Oil Flow Rate
59-430
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
137-360
mbar
Gas Line Pressure (High Pressure type)
1.5-4
bar
Input Gas Pipe Size (Low Pressure)
DN 80
Input Gas Pipe Size (High Pressure)
DN 80
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
11
kW
Fan Motor Speed
2840
rpm
Pump Model
TA 5
Pump Motor Power
1.5
kW
Pump Motor Speed
2885
rpm
Gas Operation Mode
Electrical Modular
Oil Operation Mode
Electrical Modular
Centrifugal Fan
314x101x38
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
1683x1249x741
mm
Weight
268
Kg

RLGB-M/M-505/LN

Low Nox Burner
Power: 5100 (kW)

SKU: RLGBMM505LN

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
700-5100 / 602-4388
(kW) / (Mcal/h)
NOx Class
III
Turn Down Ratio
1:7
G20 Gas Rated Output
700-5100
kW
G20 Gas Flow Rate
70-510
m3/h
G25 Gas Rated Output
700-5100
kW
G25 Gas Flow Rate
81-593
m3/h
LPG Rated Output
750-5100
kW
LPG Gas Flow Rate
29-198
m3/h
Light Oil Rated Output
700-5100
kW
Light Oil Flow Rate
59-430
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
137-360
mbar
Gas Line Pressure (High Pressure type)
1.5-4
bar
Input Gas Pipe Size (Low Pressure)
DN 80
Input Gas Pipe Size (High Pressure)
DN 80
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
11
kW
Fan Motor Speed
2840
rpm
Pump Model
TA 5
Pump Motor Power
1.5
kW
Pump Motor Speed
2885
rpm
Gas Operation Mode
Electrical Modular
Oil Operation Mode
Electrical Modular
Centrifugal Fan
314x101x38
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
1683x1249x741
mm
Weight
268
Kg
Burner Type L1 L2 L3 W1 H1 H2 D1 D2 D3 D4 N N1 N2 B.C.D B.C.D1 B.C.D2
RLGB-M/M-505/LN
1683
514
431
1249
741
413
328
20
4
490
Gas Operation
Nox (mg/kW.h)
CO (ppm)
80
20
Light Oil Operation
Nox (mg/kW.h)
CO (ppm)
170
30

Gas Operation

Nox (mg/kW.h) CO (ppm)
80
20

Light Oil Operation

Nox (mg/kW.h) CO (ppm)
170
30
