| Heat Rated Output | 400-1480 / 345-1273 | (kW) / (Mcal/h) |
| NOx Class | II | — |
| Turn Down Ratio | 1:4 | — |
| G20 Gas Rated Output | 400-1480 | kW |
| G20 Gas Flow Rate | 40-148 | m³/h |
| G25 Gas Rated Output | 400-1480 | kW |
| G25 Gas Flow Rate | 47-172 | m³/h |
| LPG Rated Output | 500-1150 | kW |
| LPG Gas Flow Rate | 19-45 | m³/h |
| Light Oil Rated Output | -- | kW |
| Light Oil Flow Rate | -- | kg/h |
| Heavy Oil Rated Output | -- | kW |
| Heavy Oil Flow Rate | -- | kg/h |
| Gas Line Pressure (Low Pressure) | 50-138 | mbar |
| Gas Line Pressure (High Pressure Type) | -- | bar |
| Input Gas Pipe Size (Low Pressure) | Rp 2 | — |
| Input Gas Pipe Size (High Pressure) | -- | — |
| Electric Power Supply Phase | 3 | ph |
| Electric Power Supply Frequency | 50 | Hz |
| Electric Power Supply Voltage | 380-400 | V |
| Fan Electrical Motor Power | 2.2 | kW |
| Fan Motor Speed | 2840 | rpm |
| Pump Model | -- | — |
| Pump Motor Power | -- | kW |
| Pump Motor Speed | -- | rpm |
| Gas Operation Mode | Double Stage | — |
| Oil Operation Mode | -- | — |
| Centrifugal Fan | 387x61x24 | mm |
| IP (With reference to ISIRI 2868) | 43 | — |
| Total Dimension | 1097x582x600 | mm |
| Weight | 78 | Kg |
