RGB-385

Power: 3800 (kW)

SKU: RGB385

5/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
650-3800 / 560-3270
(kW) / (Mcal/h)
NOx Class
II
Turn Down Ratio
1:5
G20 Gas Rated Output
650-3800
kW
G20 Gas Flow Rate
65-380
m3/h
G25 Gas Rated Output
650-3800
kW
G25 Gas Flow Rate
75-442
m3/h
LPG Rated Output
700-3800
kW
LPG Gas Flow Rate
27-147
m3/h
Light Oil Rated Output
kW
Light Oil Flow Rate
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
114-360
mbar
Gas Line Pressure (High Pressure type)
1-4
bar
Input Gas Pipe Size (Low Pressure)
DN 80
Input Gas Pipe Size (High Pressure)
DN 65
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
7.5
kW
Fan Motor Speed
2900
rpm
Pump Model
Pump Motor Power
kW
Pump Motor Speed
rpm
Gas Operation Mode
Double Stage
Oil Operation Mode
Centrifugal Fan
315x104x38
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
1690x927x741
mm
Weight
210
Kg

Burner Type L1 L2 L3 H1 H2 D1 D2 D3 D4 N N1 N2 B.C.D B.C.D1 B.C.D2
RGB-385
1689
519.5
927
741
413
325
20
4
490
RGB-385-Dimension gas staging Monoblock burner

RGB-385-Diagram gas staging Monoblock burner

Gas Operation
Nox (mg/kW.h)
CO (ppm)
120
30

Gas Operation

Nox (mg/kW.h) CO (ppm)
120
30
