the best industrial burner, boiler burner and furnace burner in the world

RLGB-255

Power: 2400 (kW)

SKU: RLGB255

0.0/5

Technical Data

Technical Data
Value
Unit
Heat Rated Output
580-2400 / 500-2065
(kW) / (Mcal/h)
NOx Class
II
Turn Down Ratio
1:4
G20 Gas Rated Output
580-2400
kW
G20 Gas Flow Rate
58-240
m3/h
G25 Gas Rated Output
580-2400
kW
G25 Gas Flow Rate
67-279
m3/h
LPG Rated Output
620-2400
kW
LPG Gas Flow Rate
24-93
m3/h
Light Oil Rated Output
580-2400
kW
Light Oil Flow Rate
49-202
kg/h
Heavy Oil Rated Output
kW
Heavy Oil Flow Rate
kg/h
Gas Line Pressure (Low pressure)
85-360
mbar
Gas Line Pressure (High Pressure type)
bar
Input Gas Pipe Size (Low Pressure)
DN 65-Rp 2
Input Gas Pipe Size (High Pressure)
Electric Power Supply Phase
3
ph
Electric Power Supply Frequency
50
Hz
Electric Power Supply Voltage
380-400
V
Fan Electrical Motor Power
5.5
kW
Fan Motor Speed
2840
rpm
Pump Model
J7
Pump Motor Power
0.55
kW
Pump Motor Speed
2840
rpm
Gas Operation Mode
Double Stage
Lamtec
Oil Operation Mode
Double Stage
Lamtec
Centrifugal Fan
360x66x28
mm
IP (With reference to ISIRI 2868)
43
Total Dimension
1260x833x600
mm
Weight
118
Kg
{{ reviewsTotal }}{{ options.labels.singularReviewCountLabel }}
{{ reviewsTotal }}{{ options.labels.pluralReviewCountLabel }}
{{ options.labels.newReviewButton }}
{{ userData.canReview.message }}

Burner Type L1 L2 L3 H1 H2 D1 D2 D3 D4 N N1 N2 B.C.D B.C.D1 B.C.D2
RLGB-255
1260
419
833
600
302
224
18
--
--
4
--
--
345
--
--
RLGB-255-Dimension dual fuel staging mono block burner

RLGB-255-Diagram dual fuel staging mono block burner

Gas Operation
Nox (mg/kW.h)
CO (ppm)
120
30
Light Oil Operation
Nox (mg/kW.h)
CO (ppm)
170
30

Gas Operation

Nox (mg/kW.h) CO (ppm)
120
30

Light Oil Operation

Nox (mg/kW.h) CO (ppm)
170
30
